Products Description
SY New No-burning Hollow Solid Simple Cheap Pallet Paving QT6-15 Concrete Block Machine New Condition Price List
1. QT6-15 concrete brick making machine use PLC intelligent control.make the man-machine interface as true.control systerm equiped with complet logic control.production program.malfunction diagnosis system and remote control function.2. Can produce the paver block with or without color on the surface.if need color.should use the face-color materail feeding device.
3. Through mold-releasing oil cyclinder. the mold box was locked into the vibration table with high rigidity to reach the synchronous vibration. so that the concrete can be fluidified and exhausted in two or three seconds to ensure the high-density.
especially suitable to produce the standard blocks. which can be piled up immediately so that the pallet investment can be saved directly.
4. The unique forcing charge system can make use of various kinds of industrial waste and material such as coal ash. cement. sand. stone. slag. and so on. The machine can severs several purposes and produce various specification standard bricks. concrete blocks. porous blocks. paving bricks etc just changing the mold.
SY New No-burning Hollow Solid Simple Cheap Pallet Paving QT6-15 Concrete Block Machine New Condition Price List
common blocks theoretical Capacity and common blocks samples
SY New No-burning Hollow Solid Simple Cheap Pallet Paving QT6-15 Concrete Block Machine New Condition Price List QT6-15 parameters | ||
Machine power | 31.25kw | |
Molding cycle | 15-20 seconds | |
Hydraulic pressure | 16-21 Mpa | |
Machine weigh | 8500KGS | |
Overall size | 7100*1500*3000mm | |
Voltage | According to your local voltage | |
Main Vibration Form | Platform Vibration | |
Pallet Size | 850*680mm | |
Applied Products | Concrete blocks. hollow/solid blocks. pavers. interlocking blocks . curbstone. colored pavers .etc. | |
Raw Material | Crushed stone. sand . cement. dust. and fly ash. gravel. slag. and other raw material etc. | |
SY New No-burning Hollow Solid Simple Cheap Pallet Paving QT6-15 Concrete Block Machine New Condition Price List Theoretical productivity | ||||||||
Items | Block size | Pcs/mould | Cycle molding | Pcs/day | ||||
Hollow Block | 400*200*200mm | 6 | 16-20s | 8640 | ||||
Porous Block | 240*115*90mm | 14 | 15-18s | 22400 | ||||
Standard Block | 240*115*53mm | 30 | 14-17s | 54400 | ||||
