Products Description
1. Particular storage and discerption material system insure the feeding accuracy and avoiding the effect of exterior material. So the products have high density.
2. Adopting synchronization vibration insures the products maker average. The frequency can change according to different technics. Low frequency in feeding material. high frequency vibration makes the different material to have a optimal vibration way.
3. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault.
2. Adopting synchronization vibration insures the products maker average. The frequency can change according to different technics. Low frequency in feeding material. high frequency vibration makes the different material to have a optimal vibration way.
3. The computer is of fault diagnosis system. Warning signal is propitious to eliminate the fault.
Our Advantages
common blocks theoretical Capacity and common blocks samples
Technique parameters | ||
Machine power | 44.58kw | |
Molding cycle | 15-20 seconds | |
Hydraulic pressure | 16-21 Mpa | |
Machine weigh | 11000KGS | |
Overall size | 9350*2520*2950mm | |
Voltage | According to your local voltage | |
Main Vibration Form | Platform Vibration | |
Pallet Size | 1300*900mm | |
Applied Products | Concrete blocks. hollow/solid blocks. pavers. interlocking blocks . curbstone. colored pavers .etc. | |
Raw Material | Crushed stone. sand . cement. dust. and fly ash. gravel. slag. and other raw material etc. | |
Theoretical productivity | ||||||||
Items | Block size | Pcs/mould | Cycle molding | Pcs/day | ||||
Hollow Block | 400*200*200mm | 12 | 20-25s | 21600 | ||||
Porous Block | 240*115*90mm | 30 | 15-20s | 72000 | ||||
Standard Block | 240*115*53mm | 60 | 15-17s | 144000 | ||||
Packaging And Shipping
Company Profile
Customer Visiting and customer working site
Recommend Products
FAQ
Q1: What is the Warranty for the machine?
A1: For the machine.we have 1 years warranty(except the wearing part ).If any quality
problems on our side occured in this period .we will take on the shipping cost and replacement.
Q2: What kinds of payment methods can be accept?
A2: Payment: T/T. Western Union. MoneyGram.PayPal.etc;
30% deposits; 70% balance before delivery
Q3: Who will pay the delivery cost?
A3: Because block machine need to be delivery by sea or road.
so customers will in charge of the delivery cost.
Q4: what's the motor voltage?
A4:Motor voltage could be customized to fit your local voltage.
Q5: Do you have Operation Instruction Manual
A5: Yes.We will send the Operation Instruction Manual to you after you purchase the machine.
A1: For the machine.we have 1 years warranty(except the wearing part ).If any quality
problems on our side occured in this period .we will take on the shipping cost and replacement.
Q2: What kinds of payment methods can be accept?
A2: Payment: T/T. Western Union. MoneyGram.PayPal.etc;
30% deposits; 70% balance before delivery
Q3: Who will pay the delivery cost?
A3: Because block machine need to be delivery by sea or road.
so customers will in charge of the delivery cost.
Q4: what's the motor voltage?
A4:Motor voltage could be customized to fit your local voltage.
Q5: Do you have Operation Instruction Manual
A5: Yes.We will send the Operation Instruction Manual to you after you purchase the machine.
